● RF Isolation : 700MHz~90GHz>70dB
● Absorber reflectivity: <-45 dB In FR2
● Fast measurement capability via TTL hardware signal trigger.
● Five-axis linkage, the system provides fast and accurate antenna measurements for DUTs of all sizes;
● According to product requirements, the equipment speed, detection distance and Angle can be defined at will.
Inner Dimension | 990 (W) * 796 (D) * 1690 (H) mm |
Outer Dimension（Without industrial control display） | 1240 (W) * 1070 (D) * 2075(H) mm |
Operation Door Dimension | 875 (W) * 750 (H) mm |
Product Net Weight | Approx.450kg |
Product Gross Weight | Approx.720kg |
Power Consumption | 1200W |
Input Voltage | 100~120/200~240VAC 50/60Hz |
Positioner Control Interface | USB Type A Female/DB9 Female for RS232/RJ45 |
Theta axis rotation | 0~360deg |
Phi axis rotation | 0~360deg |
Theta axis accuracy | +/-0.5deg |
Phi axis accuracy | +/-0.5deg |
Supported DUT Size | Maximum:215(L)*281(W)mm |
Supported DUT Weight | Max 2.0kg |
